Panasonic DVUS904L motor speed controller
Panasonic DVUS904L motor speed controller
Panasonic DVUS904L motor speed controller
Panasonic DVUS904L motor speed controller
Panasonic DVUS904L motor speed controller
|
Parameter
|
Specification
|
Notes
|
|
Model
|
DVUS904L
|
Panel‑mount type; similar to DVUS940L series models
|
|
Compatible Motor
|
Small AC/DC motors (≤400W)
|
Common in SMT conveyor systems and nozzle rotation mechanisms
|
|
Input Voltage
|
AC220V (50/60Hz)
|
Suitable for global industrial power supplies
|
|
Control Method
|
Phase control (phase angle)
|
Smooth speed adjustment with response time ≤0.5s
|
|
Speed Range
|
50–1400rpm (motor‑dependent)
|
Supports constant‑speed or proportional control modes
|
|
Protection Functions
|
Overcurrent, overvoltage, overheating, locked‑rotor protection
|
Fault code display (e.g., E01 = overcurrent)
|
|
Mounting Size
|
96×48mm (standard DIN rail)
|
Approx. 22mm thickness for space‑saving installation
|
|
Interfaces
|
Potentiometer / 0–10V analog input, forward/reverse control
|
Compatible with PLC signal integration
|
