FUJI NXT H01 Placement head H01 WORK HEAD UH00665 AA15X19 | SMT Pick-up and Placement Machine

Brand:

SKU: FUJI NXT H01 Placement head H01 WORK HEAD UH00665 AA15X19 Categories: , Tags: ,

Model Specifications: The model is H01 WORK HEAD UH00665 AA15X19. It belongs to the FUJI NXT H01 placement head series and is a mid – term upgraded model of the NXT platform, launched around 2008.

Number of Nozzles: There is only 1 nozzle (Nozzle quantity: 1).

Applicable Component Dimensions: It can handle components with dimensions ranging from 1608 (0603″) to 74 x 74mm, meeting the placement requirements of various components of different sizes. The maximum height of the components that can be placed is 25.4mm.

Compatible Machine Models: It is suitable for mounters such as NXT III, NXT IIIc, AIMEX III, and AIMEX IIIc.

Performance Parameters: In the standard mode, the placement accuracy is ±0.03mm Cpk≧1.00, and the placement speed can reach 4200 CPH.
