Product Introduction
The Siemens ASM ESD Static Control Conductive Cloth Label Feeder is a precision automatic feeding solution engineered for Siemens SIPLACE SMT assembly lines, focusing on reliable delivery of conductive cloth labels for ESD (electrostatic discharge) protection and EMI shielding. Designed with German manufacturing technology, this feeder integrates seamlessly with SIPLACE SX, X, D, and HS series machines, supporting standard SMT reel formats and plug-and-play operation for non-stop production.
With ±0.1mm feeding accuracy and low-tension material handling, it safely conveys thin, flexible conductive cloth materials—typically woven polyester or cotton coated with conductive metal fibers—without stretching, tearing, or compromising their conductive properties. It supports label widths from 2mm to 60mm and material thicknesses of 0.05–1mm, with adjustable speed and auto-calibration functions to ensure consistent performance in high-volume SMT workflows.
Ideal for consumer electronics, automotive electronics, and medical device manufacturing, this feeder automates conductive cloth label placement to dissipate static charges, protect sensitive PCB components from ESD damage, and provide EMI/RFI shielding. Built for 24/7 operation with a no-carbon brush design for extended service life, it reduces manual errors, improves throughput, and meets RoHS, ISO, and CE certification standards, making it a reliable static control solution for modern SMT lines.
Compatible machine models
|
Siemens Machine Series
|
Compatible Siemens SIPLACE Models
|
Feeder Compatibility Description
|
|---|---|---|
|
SIPLACE X Series
|
X2, X3, X4, X4i, X5
|
Perfectly matches the feeder’s precision control, supporting stable feeding without material damage
|
|
SIPLACE D Series
|
D1, D2, D3
|
Compatible with the feeder’s low-tension design, ensuring reliable ESD protection
|
|
SIPLACE SX Series
|
SX1, SX2, SX3
|
Supports standard SMT reel packaging, easy to install and operate
|
|
SIPLACE High-Speed Series
|
HS1, HS2, HS3
|
Adapts to high-volume production, maintaining stable feeding accuracy
|
Compatible label types
|
Compatible Label Type
|
Material
|
Application (Purpose)
|
|---|---|---|
|
Standard Conductive Cloth Label
|
Woven polyester + copper/nickel conductive coating
|
General SMT ESD protection for common PCB components
|
|
High Conductivity Conductive Cloth Label
|
Woven cotton + copper-nickel alloy conductive layer
|
Rapid static dissipation for high-precision SMT production lines
|
|
EMI Shielding Conductive Cloth Label
|
Polyester + silver-plated conductive fiber
|
EMI/RFI shielding for sensitive electronic components in SMT
|
|
SMT-Specific Conductive Cloth Label
|
Polyester-cotton blend + conductive adhesive
|
Automatic SMT assembly line labeling and ESD protection
|
The conductive cloth labels for the Siemens ASM feeder are made of woven polyester/cotton with conductive metal fiber coating. They have stable conductivity, good adhesion, fit SMT reel packaging, and protect PCB components from static damage.
