Siemens ASM FPC Steel Reinforcement Label Feeder for Flexible PCB
Shock absorption and stability are key to FPC steel reinforcement assembly. The Siemens ASM FPC Steel Reinforcement Label Feeder provides high-precision feeding for FPC steel reinforcement labels, compatible with multiple SIPLACE models. It supports various high-quality steel materials, widely used in consumer electronics, automotive electronics and medical equipment FPC assembly, effectively enhancing FPC hardness and service life, and ensuring the stability of SMT production lines.
Get a free quote
Please feel free to tell us what you need! we are here to help!
The Siemens ASM FPC Steel Reinforcement Label Feeder is a high-precision automatic feeding device specially designed for flexible PCB (FPC) steel reinforcement processes. It integrates advanced closed-loop control technology to ensure stable and damage-free feeding of steel reinforcement labels, effectively solving the problems of easy deformation and inaccurate positioning during FPC steel reinforcement. Widely used in consumer electronics, automotive electronics and medical equipment fields, it provides reliable feeding support for FPC steel reinforcement assembly, improves production efficiency, reduces manual errors, and meets the high-precision assembly requirements of flexible circuit boards.
Machine Performance & Compatible Model
|
Machine Model
|
Performance Description
|
|---|---|
|
SIPLACE SX
|
Suitable for small-batch FPC steel reinforcement feeding, compatible with standard SMT reels, featuring simple operation and stable performance, ideal for basic FPC assembly scenarios with low to medium precision requirements.
|
|
SIPLACE SX4
|
Enhanced feeding stability compared to the SX model, supports 5-50mm width steel reinforcement labels, anti-wrinkle and anti-deformation design, suitable for small to medium batch FPC production.
|
|
SIPLACE X2
|
High-precision feeding with ±0.1mm accuracy, supports thin and narrow steel reinforcement labels, auto-calibration function, suitable for medium-high precision FPC steel reinforcement processes in consumer electronics.
|
|
SIPLACE X4i
|
High-speed and high-precision feeding, compatible with various steel reinforcement label sizes, heat-resistant design, suitable for mass production of FPCs in automotive electronics assembly lines.
|
|
SIPLACE TX
|
Top-level precision feeding, supports high-temperature resistant steel reinforcement materials, low noise and low failure rate, ideal for high-end FPC assembly in medical devices and aerospace electronics.
|
|
SIPLACE D1
|
Compact design, suitable for small-width steel reinforcement labels (2-30mm), easy maintenance and low cost, perfect for small-batch precision FPC assembly.
|
|
SIPLACE HS50
|
High-speed feeding up to 50 labels per minute, compatible with mass production lines, stable operation for 24 hours, suitable for large-scale FPC steel reinforcement in consumer electronics industry.
|
Supported Materials
|
Material Type
|
Material
|
Main Application
|
|---|---|---|
|
Standard FPC Steel Reinforcement Label
|
High-quality 304 stainless steel + pressure-sensitive adhesive
|
Reinforce FPC boards, enhance structural hardness, prevent bending or damage during assembly, transportation and use in general electronic products.
|
|
Anti-static FPC Steel Reinforcement Label
|
304 stainless steel + anti-static coating + conductive adhesive
|
Reinforce FPCs with sensitive electronic components, provide ESD protection, avoid static damage to chips and circuits in precision electronics.
|
|
High-Temperature FPC Steel Reinforcement Label
|
Heat-resistant stainless steel (430 series) + high-temperature adhesive (up to 260℃)
|
Suitable for FPC assembly in high-temperature reflow soldering processes, ensuring stable adhesion and reinforcement effect in automotive and industrial electronics.
|
|
Thin FPC Steel Reinforcement Label
|
Ultra-thin stainless steel (0.05-0.1mm) + low-thickness adhesive
|
Reinforce thin and flexible FPCs (such as wearable devices), maintain FPC flexibility while enhancing local hardness, without affecting product miniaturization.
|
