Panasonic M91A40GD4L motor
Panasonic M91A40GD4L motor
Panasonic M91A40GD4L motor
| Parameter Item | Specification | Remarks |
| Model | M91A40GD4L | 40W single-phase reversible AC motor |
| Motor Type | Single-phase 4-pole reversible induction motor | Suitable for frequent start/stop & forward/reverse scenarios |
| Rated Power | 40W | Ideal for small SMT transmission mechanisms |
| Input Voltage | AC220-230V (50/60Hz) | Compatible with global industrial power supplies |
| Rated Speed | 1275rpm (230V, 50Hz) | Speed varies linearly with frequency |
| Rated Current | 370mA | Low power consumption, energy-efficient |
| Max Output Torque | 0.31Nm | Meets light-load transmission requirements |
| Insulation Class | Class B | Heat-resistant up to 130℃ |
| Protection Class | IP40 | Dust-proof, suitable for industrial environments |
| Mounting Dimensions | 105×90×90mm | Flange-mount design for standard installation positions |
| Bearing Type | Ball bearing | Service life ≥ 10,000 hours |
